LC-JKLG60 Aotumatic Multi Function Round Pipe Twisting Machine

This LC-JKLG60 Aotumatic multi function round pipe twisting machine can draw and process spiral round tubes, line square tubes, flat tubes with different thicknesses and patterns.
The machine can produce and process round pipe with a diameter of no more than 60mm and a thickness of less than 1.2mm into spiral tubes. The round pipe can be made into square tube, 6 corner tube, 8 corner tube, 16 corner tube and other patterns.
Pulling the machine can process various patterns in stainless steel under special molds. The processed material is not only beautiful in appearance, durable and strong, but also because it is hollow. The material will be double the material cost of solid material. It is an essential machine for processing doors, windows, stairs, handrails and fences
24 hours online service, Let us know if you have any questions!
TECHNICAL PARAMETER
Model :LC-JKLG60
Processing material: Round tube≤Φ60mmx1.2mm
Dimensions of the finished product :

Round tube≤Φ60mmx1.2mm
Flat tube ≤ 60x30x1.2mm
Square tube≤15x15x1.2-60x60x1.2mm
Power: 7.5KW
For free dies :6sets
Voltage: 220V/380V/415V
Packing Dimension:800*1200*700mm
N.W. (kg): 1100     G.W. (kg): 1150

Inquiry

Contact us page form

Description

LC-JKLG60 Aotumatic multi function round pipe twisting machine
There are two kinds of machines for twisting round tube,They only differ in the processing range.
LC-JKLG60 machine can process round pipes with a diameter of less than 60mm.
LC-JKLG120 machine can process round pipes with a diameter of less than 120mm.
Processing material: Round tube
There are several different tubular shapes after processing by the round tube twisting machine, the mold for this machine can be customized according to customer needs.

Wrought iron pipe-twist and bend machine copper pipe twisting machine
Wrought iron pipe-twist and bend machine copper pipe twisting machine
New automatic round pipe twisting machine for square pipe twisting shape
New automatic round pipe twisting machine for square pipe twisting shape
Electric metal twisting machine twist forming metal gate door processing equipment

Functions

LC-JKLG60 Aotumatic multi function round pipe twisting machine
This machine Can process round tubes into tube types with different patterns.

Finished products by pipe twisting machine
Finished products by pipe twisting machine

Die Options

LC-JKLG60 Aotumatic multi function round pipe twisting machine
6 sets free moulds will come with machine,the mold for this machine can be customized according to customer needs.

moulds of round pipe twisting machine
moulds of round pipe twisting machine
moulds for pipe twisting machine
moulds for pipe twisting machine

Finished Product

LC-JKLG60 Aotumatic multi function round pipe twisting machine

Fully automatic multi-functional round tube twisting machine
Fully automatic multi-functional round tube twisting machine
Automatic tube threading pipe twisting machine
Automatic tube threading pipe twisting machine
Wrought iron pipe-twist and bend machine copper pipe twisting machine
Wrought iron pipe-twist and bend machine copper pipe twisting machine
Forged metal products
Forged metal products

Packaging

Packaging standard:
Dust cover + iron frame + wooden box packaging.
Mode of transportation: By car or by sea.

wrought iron machines
wrought iron machines
Packaging photo of forging machinery
Packaging photo of forging machinery
Forging machinery loading photos
Forging machinery loading photos
Metal craft accessories loading picture
Metal craft accessories loading picture
